Saltwater Demands More-Dakota Lithium Delivers
The Choice Of Champions
Specifications
-
11 Year Warranty World beating, best in class, eleven year manufacturer defect warranty.
-
Storage Capacity: 60 ampere hours (Ah). Dakota Lithium batteries provide consistent power for all 60 amp hours. DL LiFePO4 batteries have a flat voltage curve, which means they have a steady power output as the battery discharges. The power output will not dramatically drop like similar sized SLA batteries. You get all the juice down to the last drop.
-
Voltage: 36V. Can be wired in parallel up to 10 units for more capacity and a longer run time. Not intended for wiring multiple batteries in series, 36V systems only. For 72V batteries systems see our 72V single battery.
-
Energy: 2,304 Watts (Wh)
-
Terminals: M8 bolt size. Easy to adapt to different connection needs. (Max torque 15 ft. lbs.)
-
Size: 13”L x 6.7”W x 8.7”H (331mm x 172mm x 221mm). Group 31 marine battery. Same case size as a standard 12V 100Ah lead acid or AGM battery.
-
Weight: 44 lbs (20 Kg). That's 75% lighter then a lead acid battery and 25% lighter than Dakota Lithium original 36V 63Ah battery.
-
Lifecycles (battery lifespan): Up to 80% capacity for 5,000 cycles in recommended conditions. The typical SLA has 500 cycles. Dakota Lithium batteries last so long that the price per use is a fraction of traditional batteries.
-
Operating temperature: Ideal for rugged & harsh environments. Much better than SLA or other lithium’s. -4°F to 140°F (-20°C to 60°C) optimal operating temps. Avoid charging below 32'F.
-
Discharge: 60 A max continuous, 180 A max pulse 30 second pulse.
-
Charge: 30A max, 42V max recommended. Please note: this battery should be charged between 32°F to 113°F (0°C to 45°C) and with a LiFePO4 compatible charger.
-
Includes active BMS protection: Contains a circuit that handles cell balancing, low voltage cutoff, high voltage cutoff, short circuit protection and high temperature protection for increased performance and longer life.
-
Certifications: All batteries are UN 38 certified. Dakota Lithium's cells are UL1642 certified and have been tested per IEC62133 standards. Meets all US & International regulations for air, ground, train, & marine transport.
-
ISO 9001:2015 Certified: Dakota Lithium is ISO Certified per 9001:2015 standards, and select models are produced in ISO 14001 certified facilities.
-
Recommended Charger: 36V 8A LiFePO4 charger
