Automotive Battery
Cranking
Specifications
-
Best in Class 11 Year Warranty: World-class quality with an eleven-year manufacturer defect warranty.
-
Storage Capacity: 20 Ampere hours (Ah). Dakota Lithium batteries provide consistent power for all 20 Amp hours. DL LTO batteries have a flat voltage curve, which means they have a steady power output as the battery discharges. The power output will not dramatically drop like similar sized SLA batteries. You get all the juice down to the last drop.
-
Chemistry: Lithium Titanium Oxide (LTO)
-
Voltage: 12.0V
-
Watt Hours: 240
-
Low Voltage Cutoff: 7.5±0.03V
-
Size: 8.15"L X 6.89"W X 7.48"H (207mm X 175mm X 190mm) Group Size 21, but is compatible with battery sizes: 49, 99, 99R, 102R, 140R
-
Weight: 11.02lbs (5kg)
-
Terminals: SAE Terminal (Standard Automotive Post)
-
Cold Cranking Amps: 1100A (850CCA @ -18°C)
-
Emergency Jump Start Technology: This feature is designed with the possibility of a drained battery in mind. The built-in Battery Management System (BMS) Jump Start function retains a 25% state of charge. When activated, it releases this remaining 25% to help you start your vehicle. If you accidentally leave your lights on and drain your battery, simply press the jump start button to get your vehicle started!
-
Lifecycles (Battery Lifespan): 10,000 Cycles
-
Operating Temperature: -40°C - 60°C
-
Max Continuous Discharge: Peak charge acceptance 220A max for 30 seconds, 220A max BMS cutoff. Max continuous charge 200A. 14.4V recommended, 15.5V max. BMS protection from overcharging will cut off at 15.5V. LiFePO₄-compatible charger that charges at the recommended 14.4 volts.
-
Max Charge Voltage: 15.5V
-
Max Charge/Alternator Size: Peak charge acceptance 220A max for 30 seconds, 220A max BMS cutoff. Drop-in replacement for lead acid and AGM starter batteries for vehicles. Limited to a max alternator size of 220 amps or less per battery (link multiple batteries in parallel for alternators >220 amps).
-
High-Temperature Protection: -4°F - 185°F (85°C)
-
Low-Temperature Protection: None
-
Charge Temperature: -140°F (-20°C - 60°C)
-
Discharge Temperature: -40°F - 140°F (-40°C - 60°C)
-
Approx. Charge Time: 6.67 hrs with 3A, 2 hrs with 10A
-
Internal Heating: None
-
IP Rating:: IP65
-
Max Parallel: 4
-
Max Series: 2
-
Certifications: UN38.3
-
ISO 9001:2015: Dakota Lithium is ISO Certified per 9001:2015 standards, and select models are produced in ISO 14001 certified facilities.
