AIMS Power 5000 Watt Pure Sine Inverter - 12 volt 50/60 hz Industrial

AIMS Power 5000 Watt Pure Sine Inverter - 12 volt 50/60 hz Industrial

$1,199.00 $1,299.00

You Save: $100.00 8%

.. people are viewing this, and 3 recently purchased it

Fast Free Shipping on orders over $100
Lowest Price Guarantee
No Sales Tax Outside CA & WY!
Today Only - Spend $250 and get $20 off! Type KEEPITSIMPLE in checkout!

Introducing the AIMS Power 5000 Watt Pure Sine Inverter, an industrial-grade power inverter designed to perform in harsh environments. Completely overhauled, this inverter is now FCC certified and features a dual GFCI outlet, providing increased efficiency with less noise through its thermally controlled fan.

Powered by a DSP (Digital Signal Process) drive, this 5000-watt inverter delivers pure sine power, making it ideal for running nonlinear loads such as variable-speed motors and small compressors. It's also perfect for sensitive electronics like laser jet printers, computer servers, medical equipment, and more.

This pure sine wave inverter can be used for off-grid home backup power systems, solar and boat applications, work vehicles, tiny houses, and RVs. With 5000 watts of continuous power and 10000 watts of surge power, you can work or play practically anywhere.

Featuring a 12 Volt DC input, 60hz or 50hz switch, and >95% efficiency at 1/3 load, this inverter is highly efficient, delivering efficient output even at low voltage. It also includes an external battery voltage sensor to monitor your battery capacity and power consumption.

The AIMS Power 5000 Watt Pure Sine Inverter is equipped with a range of safety features, including short circuit protection, GFCI and AC breaker, and a five-function protection LED indicator. Dual cooling fans keep the inverter operating at optimal temperature, and an included DC volt meter and instruction manual make installation and use a breeze.

AIMS Power offers lifetime tech support and a one-year warranty for parts and labor replacement. Experience reliable, efficient, and safe power with the AIMS Power 5000 Watt Pure Sine Inverter.

Features:

5000 Watt continuous power
10000 Watt surge
12 Volt DC input
Pure sine wave
60hz or 50hz switch
Highly efficient : > 95% @ 1/3 load
Efficient output at low voltage
2 - GFCI Dual Outlet
Direct connect AC Terminal Block Connector and
Cable for optional remote on/off switch
Isolated ground & neutral
Short circuit protection (GFCI and
AC Breaker)
On/off switch
5 Function Protection LED indicator
AC Breaker
Dual cooling fans thermally controlled
DC volt meter included
Instruction manual
Lifetime tech support
1 Year Warranty Parts and Labor replacement

Specifications:

DC Input Voltage 13.2 V (10.5V-15V)
Output Voltage no load 120Vac +/- 3%
Continuous 5000 Watts
Surge 10000 Watts (1/2 second)
91% Efficiency @ full load
No Load Current (Fan Off) 2.6A 12V
No Load Current (Fan On) 4.4A 12V
Low Battery Shut Down: 10.0V
Low Battery Return on Power: 11.2V
High Battery Shut Down: 15.9V
High battery return on Power: 15.0V
Frequency Selection 50/60hz
Over Temperature Protection: -25ºC - 79ºC
Cooling Fan on Temperature: 40ºC
GFCI Outlets rated at 20A per block.
Dimensions (inches) 23.75 x 8.88 x 6.25
Weight: 27lbs

Downloads:

AIMS 5000 Watt Pure Sine 12 Volt Power Inverter - PWRIG500012120S Users Manual
